National Item Identification Number

00-040-2248
000402248
2520-00-040-2248
2520000402248

National Stock Number

Item Name

LEVER,REMOTE CONTROL

Federal Supply Class

2520

Description

A rigid item usually in the form of an arm of various shapes and cross sections, containing two or more holes so spaced that one serves as a pivot with or without hubs and must have a definite means for securing to a shaft (such as threaded hole for set-screw, keyway(s), splines, serrations or some clamping device). The other hole(s) connect(s) to CONNECTING LINK, RIGID; WIRE ROPE ASSEMBLY, SINGLE LEG; or CLEVIS, ROD END; to provide transmission of movement to other parts of the mechanism. See also BELL CRANK. For manually operated items see LEVER, MANUAL CONTROL.

Commercial and Government Entity Code (Supplier Data)

---

19207

---

---

NSN (National Stock Number) 2520-00-040-2248, 2520000402248 NIIN (National Identification Number) 00-040-2248, 000402248

Part Numbers (Reference Numbers)

KC6139
7376155

Required Categories

MATERIAL
MATERIAL DOCUMENT AND CLASSIFICATION
SURFACE TREATMENT
OVERALL WIDTH

Required Description

STEEL
66, SAE 1020 THROUGH 1035 FED STD SINGLE MATERIAL RESPONSE
PAINT
1.375
